Subsize 90mm USB swipe hico loco stripe card magnetic card reader msr

Memory / Card Reader

Model No. MSR900
This magnetic stripe card encoder is idealfor access control, time keeping, ID recognition verification and related applications. In fact, wherever a magnetic stripe ID or transaction card is used, one can find a related use for the versatile, user-friendly MSR900 reader/writer.
The MSR900 is designed to offer a reading and writing solution of high and/or low coercivity cards that will attractively complement an existing system.
Specification
Standard
ISO7811
Data structure
" %":1 Track Data "+": 2 Track Data "?": 3 Track Data
Electrical
Consumption
Current/operating Typical 350mA Max
600mA plus for each writing track
Communication
Standard RS232 signal voltage levels. Default, 9600 Baud, None Parity, 8 bits
Power supply
External switching Power 24V/2.2A regulated
Interconnection
Cable
USB
Pin Assignment
USB
1. power
2. TXD / data transmit
3. RXD / data receive
4. circuit ground
Environment
Operation
-10ºC to 60ºC
10 to 85% humidity, non condensing
Storage
-30ºC to 70ºC
10 to 90% humidity, non condensing
Performance
Read Circuit
Track 1&3 210bpi
Track 2,75 or 210 bpi
Bit per Char
5-7 bit per char.
Media Speed
Read, 5-50 ips (read speed 5-40 ips for track 2 at 210bpi)
Write, 5-30
Media Coercivity
Read 300-4000 Oe Mag. Card
Write 300-4000 Oe Mag. Card
Media Thickness
0.76-1.2mm
Jitter Card
Read bit to bit interval <+/-15% card
Write bit to bit interval <+/-10%,Sub interval<+/-12% at 30ips
Low amplitude Card
Read 60% for both 75& 210bpi
Error Rate
Read < 0.5%
Write < 0.8%
Media Swipe
Head life 1,000,000 passes for both read & write head
Configuration
Available Model
Model
Read/Write Track
Hi-C
Lo-C
MSR900
1&2&3
R/W
R/W
General Description
The MSR900 series is designed to read and/or write high or low coercivity magnetic cards. It can encode and verify up to 3 tracks of data simultaneously. It communicates with a host computer or other terminal using a usb interface.
Application:
- ID Identification
- Magnetic card, Membership ID card
- Security Management System
- Tax-Controlled System
- Others
