sdk/mini magnetic stripe card reader software msr-HCC1001.Introduction:
ContactICcardreaderthroughthecontactsontheICcardreadingand writing cards,is the most common reader.Widely used in industry and commerce,tele-communications,taxation,banking,insurance,healthcareand avarietyofcharges,storedvalue,querymanagementsystem.Thereaderis programmablesothatthedataformatandintelligentinterfaceoutputcanbe programmed&configured tomatchapplicationandcommunication requirements.
2.Features:
l Canread&writeavarietyofmemorycardandsupportsT=0andT=1 communicationprotocol CPUcard
l SupportthefunctionoftheSAMcardoperation
l UseUSB tocommunicationwith PC
l Provide many development platform interface function and application example
3.TECHNICALSPECIFICATION:
ICCardSupported
AT24C01A/24C02/24C04/24C08/24C16/AT24C64,SLE4432/4442,SLE4418/4428,
ISSI24C01A/16,ISO7816-(1-4)(T=1,T=0)
Communications
USB2.0,reallyPlugandPlay
Maximumpowerconsumption
100mW
Temperature
Commercial-grade:-20°∼60°C
Industrial-grade:-20°∼60°C
Humidity
90%non-condensing
Anti-staticinterference
15KV
Magneticinterferenceresistance
19Oersted
Vibrationresistance
Amplitude 0.35mm,Frequency10-55Hz,Three
Axisdirectionssweepvibration
InsulationResistance
Hot and humid circumstances(40 °,
95%)Insulation resistance should not be lessthan5MΩ
Dimensions
100mm(L)×34mm(W)×30mm(H)
Weight
85g
ICcard
ReferenceStandards
ISO-7816ClassA,BandC
OperatingLife
approx.100,000passes
Cardthickness
About0.75mm
