OVERVIEW
The device is a microelectronics RF receiving module and an embedded microcontroller, combined with an efficient decoding algorithm and advanced data processing technology to read the non-contact card. After several years of upgrading and improvement, the equipment has been very stable, mainly applying member management system, KTV vod system, Internet cafe management system, as a card issuing and card reading device for all kinds of card systems.
1.Card reading type:IC card
2.Working frequency 125khz Optional 13.56MHZ, support ISO14443 TYPE A/B standard
3.Communication format:USB
4.Plug and play, no need to drive automatic identification
5.Power supply mode:5V USB, no external power supply, and built-in power protection. Can be extended to 5 meters
6. An LED indicator and a buzzer. When the card is swiped, the buzzer will sound and the indicator will flash.
7.Power supply 0.2 (W)
8.Reading distance:0-15CM
9.Reading time:<100ms
10. Supports Windows/XP/WIN7/WIN10, 32-bit and 64-bit systems are supported.
11.Appearance of the popular male mold
(size:length width height) 10.8cm 7.8cm 2.8cm Weight about 0.23KG
12.Output data is to convert the low four-byte serial number in the card into ten decimal digits, and press Enter. If you need other formats, please customize our company.
13. Connected to the computer USB, belonging to the computer external input device, the card is equivalent to the keyboard automatic input number, input at the software cursor and automatically enter.
14.Can be connected to Android phone Automatic identification (order instructions)
| Item | Parameters |
| Model | R10D(LF-ID Reader) |
| Frequency | 125Khz |
| Support cards | Em4100,TK4100,SMC4001 and compatible card |
| Output format | 10 digit dec(Defoult output format)
(Allow user to customize the output format) |
| Size | 110mm80mm26mm |
| Colour | Black |
| Interface | USB |
| Power Supply | DC 5V |
| Operating Distance | 0mm-100mm(related to the card or the environment) |
| Service Temperature | -10 ~ +70 |
| Store Temperature | -20 ~ +80 |
| Working humidity | <90% |
| Read time | <200ms |
| Read interval | <0.5S |
| Weight | About 160G |
| Cable length | 1400mm |
| Material of reader | ABS |
| Operating System | Win XPWin CEWin 7Win 10LIUNXVistaAndroid |
| Indicators | Double Color LED (Red & Green) and Buzzer
(“Red” means standby, “Green” means reader success) |
