Specification
Model H8922S
ulti-carrier (3G/4G LTE) YES
Dual SIM YES
Remote Manager(Wedora Cloud Platform) YES
WAN 1
Ethernet Port 4
Wlan/WiFi YES
Serial Ports(optional) 2
Interface Options AC Wi-Fi, GPS
Digital I/O 3
USB -
LED Indicator 12
Power Supply 5-36V
Enclosure Industrial metal case, Wall Mounting
Dimension(mm) 191.5*112*26
Weight 340g
VPN IPSec / OpenVPN / GRE / L2TP / PPTP / DMVPN
Management WEB/CLI/SNMP / Hongdian Wedora Cloud
Working temperature -30~+75
Storage temperature -40~+85
Safety Standards GB/T 25119
EMC Standards EN61000-4-2,level 4
EN61000-4-3,level 3
EN61000-4-4,level 4
EN61000-4-6,level 3
EN61000-4-8,>level 4
CISPR 22,CLASS B
CISPR 22,CLASS B
Mechanical Environmental testing IEC60068-2-27
IEC68-2-29
IEC68-2-32
IEC68-2-6,JT/794
Applications
Self-serivce Machine
Electronic Ticket Self Check-in
ATM


Our CertificationsSuccessfully passed various global certifications, including CE, FCC, CCC, IC, RoHs ,etc.

Quality Assurance Since years, we have implemented ISO9001:2008 Quality Management system with sophisticated methods of quality planning, quality control, quality assurance and quality improvement.

Exhibition Show Hongdian has entered the international market since 2005. since years, products are exported to more than 120 countries and help customers connect over 5 million device.
