20w-60w series
70w-120w series
130w-200w series
Product Pircture



Project casesParts of the Installation cased of the sword streetlight throughout the word


Installation Instructions1. The ex-factory of the standard components of the LED street lights include a 3*1mm2 cable .The power supplywire should suffer the voltage ≥300/500V,the copper cross-section ≥ 0.75 mm2 of 3 copper wires inside.Theinstallation and wiring connection should be carried out after turning the power off. Before wiring connection,theoperator must check the polarity of power supply to prevent the damage of controller fuse and lamp.The mode ofconnection is shown by the picture as below:
2. Insert the street light holder into the pole arm . The diameter of pole arm is 50 mm.The length ofconnective part is 60-65mm.Adjust lamp to desired level ,wrench the M8 secure screws until tightened.
3. Switch on the power and make sure the light is on.Then the installation is done.
Detailed Images
Product details



Adopting LUMILEDS 5050 led light sources and LEYOND lens technology, 8% light efficiency higher than the same type lights in the market, high light transmittance up to 98%.
Very high quality MW power supply, input voltage AC 85-277V. The power efficiency is more than 90%, power factor greater than 0.98.
Absolutely unique DESIGN, nothing on the market like it. Make your lighting special and fantastic.
Introduction of product advantages or application effect or application mode
Connect to the pole when install the lamp
Lamp tail adopt 60mm diameter, fitness for all the market throughout the world.
Install angle adjustable from 90-30 degree.
AC electrical wiring length 90 mm for standard product, If special length sure its available, just negotiate more.
Back hood hole could be drilled, for extend function eg: NEMA 7 pin socket, daylight sensor socket.


NEMA 7 pin Socket
The most popular extend function of the smart dimming street light in this day and age.
Connect the 0-10v driver, Meanwell brand or Inventronics or Sosen optionable
By control the LORA gataway to control each LORA master on the NEMA socket.
The way of Smart lighting system
LORA Gateway dimming system diameter
In order to make it compatible with your market LORA gataway, we suggest you take the LORA knobs and LORA master from your local supplier.
Of course if you wanna take the system from us here is warmly welcomed. contact Pure for more details.


Optical daylight sensor 3 pin introduction
When the sunshine getting weak in dusk, when the ambient surround lux lower than 10 lux (or by customer special indirection), the light turn on automatically;
After a night's light up work, then the dawn comes, when the surround lux higher than 30 lux (or by customer special indirection), the light turn off automatically.
Product Presentation
Product General Infomation

Product Name
LED Street Light
Material
Die Casting Aluminium
Power
20w - 30w - 40w- 50w- 60w - 70w - 80w - 90w - 100w - 120w130w- 150w - 180w - 200w
or special requests pls contact Mr Pure to discuss more
Voltage
AC Input 85-265V
Type of Lamp-house
Unique design housing
Model
Small / Middle / Huge
Color Tempreture
Pure White:6500K / 5700K / 5000KNatural White:
4000K
Warm white:
3000K
Product weight & package info & installation tips
Power
Lamp module
lamp weight
lamp tail diameter
wire length
Install height
50W
1 module
2.75 KG
50mm / 60mm
90mm
4-8m
100W
2 modules
5.5 KG
60mm
90mm
6-10m
150W
3 modules
6.9 KG
60mm
90mm
8-14m


Certificate
All the LED street lights has passed Tuv CB CE RoHS GS SAA UL DLC certificate.Whilst we got bellow certificates & test reports if you need:
- IEC
- LM-79
- LM-80
- Salt Spray
- CIE-140-2000 (Dialux simulation)
- ISO
- IP66
- IK10
