Product Show


Product Feature
1
Nordic nRF52833 with ARM Cortex M4F
2
Multiprotocol support:
Bluetooth5.1, ANT/ANT+,and 2.4Ghz proprietary, 802.15.4 Thread and Zigbee.
3
Bluetooth 5: 2Mbps,1Mbps, 500kbps,125kbpsBluetooth5.1 Direction Finding AOA/AOD
4
IEEE802.15.4-2006:250kbps
5
Proprietary2.4GHz:2Mbps,1Mbps
6
Integrated DC-DC converter
7
Serial Wire Debug(SWD)
8
Nordic SoftDevice Ready
9
Over-the-Air(OTA)firmware update.
10
Flash/RAM:512KB/128KB
11
40 General purpose I/O pins
12
15 level low-power comparator with wake-up from System OFF mode.
13
Two 2-wire Master / Slave (I2C compatible)
14
I2S audio interface
15
12 bit/200KSPS ADC
16
High-speed 32Mbps SPI
17
4 SPI Master/3 SPI Slave(8Mbps)
18
2 UART(with CTS/RTS and DMA)
19
4X4-channel PWM unit with EasyDMA
20
USB2.0 full speed (12 Mbps) controller
21
20 channel CPU independent Programmable Peripheral Interconnect(PPI)
22
Quadrature Demodulator (QDEC)
23
128-bit AES HW encryption
24
5*32 bits,3*24bits Real Time Counters(RTC)
25
TX power:+8dBm to-20dBm in 4 dB steps
26
Size: 24.3*17.5*1.8mm with Antenna
27
Integrated high performance PCB antenna
28
DC/DC on board
29
No external components required
30
Operation voltage:1.7V to 5.5 V


Typical Applications




1
2.4 GHz Bluetooth low energy systems
2
Proprietary 2.4 GHz systems
3
Sports and leisure equipment
4
Mobile phone accessories
5
Health Care and Medica
6
Consumer Electronics, Game pads
7
Human Interface Devices, Remote control
8
Building environment control / monitoring
9
ibeacon/beacons
