What is the details for Wire type valve control remote reading water meter ?
SpecificationsAMR Electronic Remote reading water meters with Auto shut off valve control ,Auto shut off water meter smart water meter,.using pre-paid way to achieve the new management
We are water meter manufacture for 10 years and we can supply Auto shut off water meter Card Water Meter & card reader ,any comments or needed ,pls feel free to comtact me:
Wire type valve control remote reading water meter
1. remote valve control;
2. advanced meter infrastructure;
3.electronic sampling technology
4. IP68 fully sealed casing
Features:
1.Valve Control avoid Payment Problem; 2. Remote Reading save manager cost; 3. efficient Meter Reading
Full Name: M-BUS Remote Reading & Valve Control AMR Water Meter
Application: Measuring the volume of cold potable water passing through the pipeline
Technical Standards: ISO4064-1~ 3: 2005,EEN13757-2004,DL/T645-1997
Product Features:
1>Confirms to EN13757-2 2004 international standard, with a favorable compatibility and openness, meanwhile supports various meter types, such as water/electricity/gas/heat meters etc.
2>Adopt two wire connection mode, enables a long communication distance and bus power supply
3>Nonpolar of the transmission line, willfully branch of the network topology, easy network, shooting the problem of meter breakdown and failure of meter reading caused by Bus line misconnection
4>Double power supply modes: lithium battery and Bus line power supply
5>Real-time reading of the current meter data and monthly data within a year
6>Low power dissipation, quiescent operation current below 5 μA, guarantee battery of a long service life
7>Remote valve control, facilitating the user management
Technical Data:
Items
Contents
Water Temperature
0.1°C-50°C
Working Pressure
1.0MPa/1.6MPa
Head Loss
0.063MPa
Max. Permissive Error
maximum permissible error: upper zone(Q2≤Q≤Q4),±2%;low zone(Q1≤Q<Q2), ±5%
Base Meter Parameters:
DN Metrologic Class Permanent Flow Q3 Q3/Q1 Min. Reading Max Reading
mm Class B m3/H / m3 m3
15
2.5 80/100 0.0001 99999
20 4 80/100
25 6.3 80/100
Installation Dimension
Nominal Dia.
DN(mm)
Length L
Length L1
Width B
Height H
Connecting Thread
mm
d
D
15
259
165
96
113
R1/2B
G3/4B
20
300
195
96
113
R3/4B
G1B
25
344
225
96
113
R1 B
G1 1/2B
Why you choose us ?
MOQ:
We could accept your trial order,then you can take this opportunity to check the quality of our products & service of our company
Logo:
Buyers logo imprint accepted
Sample Policy:
We can supply you sample for checking quality,if you pay for the sample & sample freight. we will deliver to you in 1-3 days after we got your payment.
Lead time:
The normal Lead time is 15-30 days , which depends on your quantity.
Payment terms:
L/C, T/T, Western Union, MoneyGram, Paypal.
Shipping:
We can arrange the shipping by Courier ( DHL, UPS, Fedex , TNT etc. ), by air or by sea for you.
Please tell us which shipping way that you want and your detailed address, your nearest airport or seaport.
COMPANY IMAGES

CERTIFICATES

Exibition


LOADING IMAGES
