Home security Intelligent zigbee pir sensor
IX 30 is wireless wall-mounted PIR sensor adopts latest detection & induction technologies including Energy Accumulation Management, Dynamic Random Time Division Technology etc. And it combines multi-zones comprehensive induction calculation and uses advanced MCU digital processing technology. It has the advantages of stable & reliable detection, low false alarm and pet immune.
Specification
1.Imported infrared sensor, high sensitivity
2.Design of sealed induction chamber, avoid false positives by hot air interference
3.With fuzzy logic algorithm & fuzzy recognition technology, pet-immune
4.Adjustable detection sensitivity
5.LED status indication
6.Battery power real-time detection, low battery & tamper Report
7.Ultra-low power consumption, long standby time and longer battery working life
8.Custom made ZigBee/Zwave/Bluetooth/RF protocol available
Parameter
Model
IX30
Operating Voltage
DC3V (2PCS LR6 1.5V alkaline battery)
Detect Distance
≤10m @25
Freq/Communication Protocol
433,868,315,ZWAVE,BLE ,
Transmitting distance
≤120m(Open area)
Static current
≤15uA
Transmit current
≤15mA(433/315M) ≤30mA(868M)
Max Coverage
10m*10m
Infrared Area
11+8+6+5
Anti-visible Light (indoor)
6500LUX
Working Hum. & Tem.
-10~50; ≤95%RH no condensation
Dimension
110mm*62mm*47mm(L*W*H)
Detailed Images
