Gateway Block Diagra
General Gateway Block Diagram

Smart Wireless Gateway
Wireless intelligent automation control continues to evolve. To help IoT companies to expend the market quickly,
Dusun has developed two smart hubs for connecting sensors and wireless devices across models and protocols.
We are able to support on both hardware and software, help you to integrate to your own cloud. Or work with our
Dusuns own application and third platform Tuya. Our innovative intelligent gateway integrated with main protocols
including Zigbee3.0, Z-wave, Bluetooth, WiFi, and LTE to deliver the different demand in smart home, intelligent
security, smart energy, healthcare or building management system.
√ Multiple wireless protocols
√ Programmable Linux platform
√ Cloud integrations available
√ Connecting with Tuya



Parameters
Protocols Wi-Fi, Zigbee, Bluetooth,Zwave
Access Devices Up to 100
System OpenWrt
CPU MTK7620A
Wireless Distance Wi-Fi>50m; Zigbee>100m ; Bluetooth > 20m
Power Supply USB Port (5V/1A)
Working Humidity ≤95%RH,Non-Condensing
Working Temperature -5~60
Product Size 70*70*22(mm)
Pairing Key
1
Indicator LED Three ( Green ;Yellow; Red )
