Ultrasonic Water Meters with M-Bus
Ultrasonic Water Meters with M-Bus
Ultrasonic Hot Water Meters with M-Bus are very different from the ordinary simple water meters. With the higher technology and
development, the Ultrasonic hot water meters have the function of more easier installation and management. With the M-bus
function, the Ultrasonic Heat Meters can centralize the management for reading the meters from the end users. The Ultrasonic Hot
Water Meters with M-bus mainly test and calculate the volume for the water consumption.
The specification of Ultrasonic Hot Water Meters with M-Busis following:
Diameter DN (MM): DN15 DN20 DN25 DN32 DN40
qi(m3/h): 0.015 0.025 0.035 0.06 0.10
qp(m3/h) 1.5 2.5 3.5 6 10
qs(m3/h) 3 5 7 12 20
Function M-BUS, RS485, Pulse, infrared
Accuracy class 2
Pressure loss ＜25kPa
Max working pressure 1.6MPa
Temperature range 4 ~ 95
Temperature difference range 3 ~ 70
Temperature differential 0.01
Environmental grade A
Battery working time 8years
Installation way horizontal or veritical
Temperature sensor PT1000Display digits 8digits
