Slocable China Factory 2 Core 4.0mm2 Tinned Pure Copper 99.999% Solar Cable PV Wire
Advantages for Double Cores 2X4mm2Dual wall insulation. Electron beam cross-linkedExcellent resistance to U.V., water, oil, greases, oxygen,
ozone and general weatheringExcellent resistance to abrasionExcellent flexibility and stripping performanceHalogen free, flame retardant, low toxicityHigh current carrying capacityCE and TUV approved
Technical Data of Double Cores 2X4mm2
Slocable China Factory 2 Core 4.0mm2 Tinned Pure Copper 99.999% Solar Cable PV Wire - ANKUX.COM

Slocable China Factory 2 Core 4.0mm2 Tinned Pure Copper 99.999% Solar Cable PV Wire - ANKUX.COM

Type Cross Section Conductor
Diameter
Conductor Resistance Outer Diameter
A x B
Rated Voltage Rated Current Strand Design
mm2 mm Ω/km mm V DC A NO.x φ(mm)
PV-2*4.0mm2 4.0 2.6 4.97 6.90 x 11.30 1500 50 56* φ0.3
(We also produce dual core solar cables of 2 x 2.5mm2 and 2 x 6mm2, as well as single core cables, please consult me directly if necessary)
Wire: Copper, Class 5, tinned
UV resistance
Insulation material: XLPE
High wear and abrasion resistance
Double insulated
Flame test according to:
DIN EN 50265-2-1 UL1571(VW-1)
Halogen-free
Smallest permissible Bending Radius: 5 x D
High resistance against oil, greases, oxygen and ozone
Temperature range: -40~+90 (Max 120)
Microbe-resistance
Colours: Black
Slocable China Factory 2 Core 4.0mm2 Tinned Pure Copper 99.999% Solar Cable PV Wire - ANKUX.COM
