Slocable 1500V PV Cable and Wire Single Core 1x4mm2 PV1F 1169 EN50618 Solar Cable
Product Show
Detail Information for 1500V PV Cable
Dual wall insulation. Electron beam cross-linkedExcellent resistance to U.V., oil, greases, oxygen, water, fluids, salt, general weathering and ozoneExcellent resistance to abrasionHalogen free, flame retardant, low toxicityExcellent flexibility and stripping performanceHigh current carrying capacityCE, TUV and ISO approved
Technical Data of 1500V PV Cable
Slocable 1500V PV Cable and Wire Single Core 1x4mm2 PV1F 1169 EN50618 Solar Cable - ANKUX.COM

Type Cross Section Strand
Design
Conductor Diameter Conductor Resistance Outer Diameter Rated Voltage Rated Current
PV-1x4mm2 4.0mm2 56 x φ0.3mm 2.6mm 4.97 Ω/km 6.2mm 1500V 50A
Wire: Copper (Class 5, tinned)
UV resistance
Insulation material: XLPE
High wear and abrasion resistance
Double insulation
Flame test according to:
DIN EN 50265-2-1 UL1571(VW-1)
Halogen-free
Smallest permissible bending radius: 5 x D
High resistance against
oil, greases, oxygen and ozone
Temperature range: -40 ~ +90
Microbe-resistant
Colours: Black, Red
