Products Description
"Quality first, customer first" is our development policy, to provide customers with one-stop product supply program, and constantly improve our products and service system is the mission of the company. Specification table:
Conductor
Iusulator
Max.Cond
Resistance
(Ω/KM)
Size (AWG)
Construction (NO./mm)
Diameter
(mm)
Nominal
thickness
(mm)
Diameter
(mm)
Conductor resistance (Ohm/km)
30awg
7/0.10
0.30
0.78
1.86
336
28awg
7/0.127
0.38
0.78
1.94
208.57
26awg
7/0.16
0.48
0.78
2.04
139.75
24awg
7/0.20
0.61
0.78
2.17
88.90
22awg
7/0.254
0.78
0.78
2.33
57.80
20awg
7/0.31
0.92
0.78
2.50
37.60
18awg
7/0.39
1.19
0.78
2.75
23.85
16awg
7/0.49
1.49
0.78
3.05
15.10

UL３１３３WIRE
Nominal voltage600V
Rated Temperature150
StandardUL Style 31３3
Applications: Apply to headlamp,Home appliance,Industrial machine,electrothermal products.
