Dc electric cable H1Z2Z2-K 4m 6m 10m 16m solar pv cable for solar panelH1z2z2-k is 1.5KV voltage solar photovoltaic cable, photovoltaic wire and dc connection wire of solar panel under the new standard EN50618 certified by TUV. On the basis of the original PV1-F, the logistics performance remains unchanged and the electrical performance is optimized and improved a lot, providing more suitable DC connection cables for large inverters on the market.
Product name: Single Core Photovoltaic Cable
Product Model: H1Z2Z2-KApplication: For use in photovoltaic power generation systems with nominal 1.5KV DC voltage between conductor and conductor & groundSTRUCTURE:Conductor Cross-section:1.5mm²-120mm²Conductor: Tinned Copper Multistrand Wire
Advantages of Product
Dual wall insulation,Electron beam cross-linked.
Resistance to UV,water,ozone,fluids,salt,general weathering.
Halogen free,flame,retardant,low toxicity.
Flexibility and stripping performance.
TUV approved.
High current carrying capacity.
Resistance to abrasion.
Cross Section
(mm²)
Conductor Construction
(pcs/mm)
Conductor nominal Diameter
Cable nominal Diameter
(mm)
Conductor Max Resistance
AT 20 (Ω/km)
Current Capacity
AT 20 (A)
1.5
30/0.25
1.57
4.90
13.3
30
2.5
49/0.25
2.02
5.45
7.98
41
4.0
56/0.30
2.59
6.10
4.95
55
6.0
84/0.30
3.56
7.20
3.30
70

Working voltage of AC system
Line-to-earth rated voltage U0 600V AC
Line-line rated voltage U0 1000V AC
Line-ground maximum allowable voltage 720V AC
Line-line maximum allowable voltage Um 1200V AC
DC system working voltage
Line-ground maximum allowable voltage V0 900V DC
Line-line maximum allowable voltage
1800V DC
