H07VU Hot sale 2.5mm 4mm 6mm single electrical wires copper for house
Why Choose It
— It can be used for more than 70 years
— High-purity copper core, saving electricity and reducing costs
— Own brand, directly sold by the factory, the quality is standard , you can use it with confidence
Single-core wire with high safety
PVC insulation Can be customed 99%Pure copper
M
ultiple colour
DESCRIPTION
Application
The wire conductors are used for fifixed protected installations:i.e. ligths or control gear (from offifices, domestic or commercial buildings ...) with voltage ≤ 1000V AC or ≤ 750 V
DC .
Installation
Open air, in conduit, in cable trunking, in cable ducting. Thanks to the sliding properties of insulation, The wire is made to facilitate processing while pulling in.
| Cross section [mm2] | Construction
[NO./mm] | Insulation
thickness
[mm] | Diameter
[mm] | Approx. weight [kg/km] |
| 1G1.5 | 1/1.38 | 0.7 | 2.78 | 19.9 |
| 1X1.5 | 1/1.38 | 0.7 | 2.78 | 19.9 |
| 1G2.5 | 1/1.78 | 0.8 | 3.38 | 31.5 |
| 1X2.5 | 1/1.78 | 0.8 | 3.38 | 31.5 |
| 1G4 | 1/2.25 | 0.8 | 3.85 | 46.2 |
| 1X4 | 1/2.25 | 0.8 | 3.85 | 46.2 |
| 1G6 | 1/2.76 | 0.8 | 4.36 | 65.7 |
| 1X6 | 1/2.76 | 0.8 | 4.36 | 65.7 |
| All drawings, designs, specifications, plans and particulars of weights, size and dimensions contained in the technical or commercial documentation is indicative only and shall |
H07VR electrical wires 1.5mm 2.5mm 4mm 6mm 10mm 16mm 20m for outdoor
DESCRIPTION
Application
H07V-R are insulated stranded copper conductors, used for fifixed
protected installations indoors for power supply or lightings (from offifices, domestic or commercial buidings...) with voltage up to 1000V AC or 750V DC.
Installation
In conduit, insulated support, ducts... in covered an dry place.
Permissible currentare given for conductor laid alone in insulating tube on a wall temperature at 30°C .
Cross section
[mm2] | Construction
[NO./mm] | Insulation
thickness
[mm] | Diameter
[mm] | Approx. weight
[kg/km] |
| 1G1.5 | 7/0.52 | 0.7 | 2.96 | 21.3 |
| 1X1.5 | 7/0.52 | 0.7 | 2.96 | 21.3 |
| 1G2.5 | 7/0.68 | 0.8 | 3.64 | 34.4 |
| 1X2.5 | 7/0.68 | 0.8 | 3.64 | 34.4 |
| 1G4 | 7/0.85 | 0.8 | 4.15 | 49.5 |
| 1X4 | 7/0.85 | 0.8 | 4.15 | 49.5 |
| 1G6 | 7/1.04 | 0.8 | 4.72 | 70 |
| 1X6 | 7/1.04 | 0.8 | 4.72 | 70 |
| 1G10 | 7/1.35 | 1 | 6.05 | 116.8 |
| 1X10 | 7/1.35 | 1 | 6.05 | 116.8 |
| 1G16 | 7/1.70 | 1 | 7.1 | 175.8 |
| 1X16 | 7/1.70 | 1 | 7.1 | 175.8 |
