H07VU Hot sale 2.5mm 4mm 6mm single electrical wires copper for house


DESCRIPTION
ApplicationH07V­U conductors are used for fifixed protected installations : i.e. ligths or control gear (from offifices, domestic or commercial buildings ...) with voltage ≤ 1000V AC or ≤ 750 V DC .
InstallationOpen air, in conduit, in cable trunking, in cable ducting. Thanks to the sliding properties of insulation, H07V­U is made to facilitate processing while pulling in.
TYPES
BV BVR RVVB RV RVV BVVB
Cross section [mm²]
Construction
[NO./mm]
Insulation
thickness
[mm]
Diameter
[mm]
Approx. weight [kg/km]
1G1.5
1/1.38
0.7
2.78
19.9
1X1.5
1/1.38
0.7
2.78
19.9
1G2.5
1/1.78
0.8
3.38
31.5
1X2.5
1/1.78
0.8
3.38
31.5
1G4
1/2.25
0.8
3.85
46.2
1X4
1/2.25
0.8
3.85
46.2
1G6
1/2.76
0.8
4.36
65.7
1X6
1/2.76
0.8
4.36
65.7
All drawings, designs, specifications, plans and particulars of weights, size and dimensions contained in the technical or commercial documentation is indicative only and shall



Single-core wire with high safety
PVC insulation Can be customed Pure copper
